BS 5467 Cables
BS 5467 Armoured Power Cables, 600/1000V
Single-core 600/1000 V cables with solid aluminum conductor
Application
These cables are used for power and control circuits, they can offer excellent protection through the use of a heavy galvanized steel wire armour. The GSWA makes them suitable for use inside and outside buildings or for direct burial in the ground.
Construction
Conductor |
Solid Aluminum or Copper conductor, round stranded or shaped, Class 2 to BS 6460, IEC 60228. |
Insulation Colour Code |
XLPE (Cross-Linked Polyethylene) Type GP 8 or ethylene propylene rubber (GP 6) 1 Core : Brown |
|
2 Cores: Brown or Blue |
|
3 Cores: Brown, Black, Grey 4 Cores: Blue, Brown, Black, Grey 5 Cores: Green/Yellow, Blue, Brown, Black, Grey Above 5 Cores: White Cores with black numbers |
Bedding Armour Outer Sheath |
PVC (Polyvinyl Chloride) Single Core: AWA (Aluminum Wire Armour)Multi Core: SWA (Steel Wire Armour) PVC(Polyvinyl Chloride) |
Technical Information
Voltage rating 600/1000V
Temperature rating 0°C to +90°C
Bending radius 1.5mm² to 16mm²: 6 x overall diameter
25mm² and above: 8 x overall diameter
Flame retardant IEC60332 part 1, BS4066 part 1
Nominal Cross-sectional Area |
Nominal Insulation thickness |
Nominal bedding |
Nominal Alum Wire Armor dia. |
Armour strip |
Nominal Sheath thickness |
Approx. |
AprroxWeight |
|||
thickness |
width |
wire armor |
strip armor |
|||||||
mm² |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
kg/km |
|
1x50 |
1.0 |
0.8 |
0.9 |
0.6 |
2.4 |
1.5 |
16.3 |
15.7 |
460 |
|
1x70 |
1.1 |
0.8 |
1.25 |
0.6 |
2.4 |
1.5 |
18.7 |
17.4 |
560 |
|
1x95 |
1.1 |
0.8 |
1.25 |
0.6 |
2.4 |
1.6 |
20.6 |
19.3 |
690 |
|
1x120 |
1.2 |
0.8 |
1.25 |
0.6 |
2.4 |
1.6 |
22.1 |
20.8 |
800 |
|
1x150 |
1.4 |
1 |
1.6 |
0.6 |
2.4 |
1.7 |
25.2 |
23.2 |
970 |
|
1x185 |
1.6 |
1 |
1.6 |
0.6 |
2.4 |
1.8 |
27.4 |
25.4 |
1150 |
|
1x240 |
1.7 |
1 |
1.6 |
1 |
3.6 |
1.8 |
29.9 |
28.7 |
1380 |
|
1x300 |
1.8 |
1 |
1.6 |
1 |
3.6 |
1.9 |
32.4 |
31.2 |
1640 |
|
